Centre for Advanced Communications Lab.
Advanced Communication laboratory was setup as an initiation taken up by Department of Electronics and Communication, BVRITN in 2016. It is envisioned as an umbrella body, under the aegis of which all communication related activities of the Department will be coordinated. The main emphasis of the laboratory is to design and develop RF/antenna modules, radar signal processing, modulation schemes, parametric characterization of wireless modules, software defined radio applications, different wireless standards and work on research problems and innovative projects that extend the state of the art of wireless systems. The vision behind is to promote and encourage student activities, research projects and relevant courses related to this field.
Faculty Coordinator: Dr. B. R. Sanjeeva Reddy
Faculty Members: Dr. Jayshree Das, Mr. Ramesh Deshpande, Mr. B. Naresh Kumar, Dr. G Srinivas
Antennas Development Setup
This setup mainly focuses on design and implementation of printed microstrip patch antennas including the operations of obtaining wide band, dual band, tri band, linear and circular polarization.
| S.No | Major Hardware / Software | Remarks |
| 1 | High frequency Laminates | Used for Fabrication |
| 2 | Vector Network Analyzer | Used for experimentation |
| 3 | RF Connectors | Used for the feeding process |
| S.No | Software Infrastructure | Hardware Infrastructure |
| 1 | IE3D Simulator | High end CPU |
| 2 | ANSYS HFSS Simulator | Dielectric Substrates |
| 3 | CST Microwave Studio | RF Connectors, Coaxial Probes |
| 4 | MATLAB Tool box | Drilling machine, Network analyzer |
| 5 | Anechoic Chamber facility |
Radar Signal processing Setup
Radar Signal processing setup deals with a High Resolution Radar (HRR) target detection system which is basically a pulse compression radar. HRR detection system is used for processing poly alphabetic signal at larger pulse compression ratio using phase coded pulse compression sequences. Using this system it is proposed to set up coincidence detection scheme to achieve effective point/distributed target detection.
| S.No | Major Hardware / Software | Remarks |
| 1 | MATLAB Tool Box | High end CPU |
| 2 | Open Source Software | Transmitting and receiving horn antennas |
| 3 | Code seeker Hardware |
Microwave Test bench Setup
The displayed microwave test bench setup brings out the demonstration of measuring different parameters such as VSWR, reflection coefficient, input power, output power, resonant frequency, guided wavelength, cut off wave length, input impedance, gain and beamwidth for X-band range os frequencies (8-12GHz).
| S.No | Major Hardware / Software | Remarks |
| 1 | MATLAB Tool Box | Gunn power supply |
| 2 | FEKO Software | Klystron power supply |
| 3 | Slotted line section | |
| 4 | Open and short lines | |
| 5 | Frequency meters | |
| 6 | MIPS Machine |
Best paper competition award
| Sanjeeva Reddy, Vijay, Ramesh Deshpande-First prize for Best paper competition award received in Indian conference on antennas & propagation (INCAP2019), Ahmedabad, India with a cash prize of Rs.7000 |
| Vijay, IV yr ECE student awarded 3rd prize for SHAR (Satish Dhawan Space Centre)Birth Centenary celebrations at SVECW, Bhimavaram under research paper contest conducted from 21-24th Jan 2020. |
Trainings Offered
IV Year
| I Sem | II Sem |
| Training on HFSS Simulator, Novel Fractal antenna designs | Fabrication of antennas |
| Calibration process of VNA | Conference paper preparation |
| Theory and practical importance of wearable antennas | Seminar on Effective paper writing skills |
| Training and implementation process of RF inductors | Reconfigurability methods |
| Evaluation of project contest, Mini project Documentation | Major project documentation |
III Year
| I Sem | II Sem |
| Frame work on communication systems | Mini project tasks to be allotted |
| Methodologies and implementation techniques of OFDM system | Matched filter designs of tracking radar |
| MATLAB Training sessions on Mini projects allotted | Importance of Coupled inductors |
Funding project:
| Funding Agency | Title of the Project | Names of the Investigators | Funding Amount | Duration of project |
| SERB (India) | Wearable Circular Polarized Antennas for Military Personal Applications | P.I: Dr. B. R. Sanjeeva Reddy, JRF : Mr.A. Amulya Kumar | Rs.44,89,610 | 3 years |
Best Student Paper Contest:
| S.No | Title of the paper | Authors |
| 1 | Tri band Rectangular printed microstrip and koch fractal antennas for 4G/LTE applications | Durgasai teja, Rohith reddy, Gowtham. sirisha reddy, B.R.sanjeeva reddy, IA.Pasha |
Faculty Publications:
| S.No | Title of the paper | Authors | Conference with dates |
| 1 | Equivalent circuit modeling of Pentagon Slot Shaped Antenna Arrays | B.R.Sanjeeva Reddy | IEEE I2CT 2018, held at Pune from 7&8 Apr 2018 |
| 2 | Parametric analysis of dual band reconfigurable antenna for cognitive radio application | Praveenkumar,Shiva Krishna, Jayshree Das | Submitted to ICIIF 2018 Conference |
| 3 | Dual band CP microstrip antenna used for GPS and 700MHz applications | Prasad, Dharmakiran, Ramesh deshpande | Planned to Submit to a Scopus journal |
| 4 | Wide-band CLC On-Chip Band Pass Filter using passive components for Sub-THz frequency applications | Nagesh Deevi | Accepted for IEEE Discover 2018, Mangalore |
| 5 | Performance Analysis of Wearable antenna Array | B.R.Sanjeeva Reddy, A.Amulya Kumar |
PG Student Publications:
| S.No | Title of the paper | Authors | Conference with dates |
| 1 | Performance evolution of PAPAR reduction for OFDM system using interleaving combination | M.Sharath Kumar, B.R.Sanjeeva Reddy | Submitted to a UGC Journal |
| 2 | Development of slant high resolution software denied radar target detection system using Labview/simulink | M.Prashant Kumar, B.R.Sanjeeva Reddy | Submitted to a UGC Journal |
Projects
Application:Antenna Design, Antenna Testing
| Batch No | Name of the Student | Project Title | Guide | |
| ACL0001 | T. Rohith reddy, S.Sai sirisha, V. Gowtham, Ch. D. Sai Teja | Koch Fractal antenna for dual band applications | Dr.I.A.Pasha | |
| ACL0002 | S. Srujan, H. Sushank, Sanju Rathod | Design and Testing of dual band Reconfigurable Antenna for cognitive Radio Applications | Dr.B.R.Sanjeev Reddy | |
| ACL0003 | R. Shivakrishna, K. Praveen kumar | Compact square reconfigurable antenna with switchable single or Triband functions | Mrs.Jayshree Das | |
| ACL0004 | A.Sairam, P. Prasad, M. Dharmakiran | Dual band circularly polarized microstrip patch antenna used for GPS applications | Mr.Ramesh Deshpande | |
| M.Tech (2015-17) | 15211D5509 | Performance Evolution of PAPR Reduction for OFDM system using ACE and interleaving combination | Dr .B. R. Sanjeev Reddy |
UG Student Publications:
| Dr.B.R.Sanjeeva Reddy, Dr.I.A.Pasha, Mr.DS.Teja, Ms.Shirisha, Mr.Gowtham, Mr.Rohith, “Tri band Rectangular Printed Microstrip antenna for 4G/LTE applications” has received “Best Paper award” and published in Antenna Test &Measurement Society (ATMS India-18 ) pune, 6th and 7th Febraury-2018. |
| Mr.H.Sushank, Mr.H.Srujan, Mr.K.Sanju, Dr.B.R.Sanjeeva Reddy, “Parametric Analysis of Dual band reconfigurable antenna used for cognitive radio applications” published in RAPIDEET-2018, 2nd Annual National conference organizing by BVRIT, Narsapur during 20th and 21st April 2018 |
Current Projects(2017-18)
| Batch No | Roll No of the Student | Name of the Student | Project Title | Guide |
| Batch 1 | 16215A0430, 16215A0420, 16215A04C3, 16215A04D8, 16215A0409 | M Deepika, Sneha, Swetha, Saloomi,P Shilpa | Development of High resolution measurement for cardiac diagnostic instruments | Mrs. Jayshree Das |
| Batch 2 | 16215A0407,16215A04P9,16215A0431, 16215A04P1 | N Sravanthi, Y Sai Krishna, K Ravali, V Dileep Raj | Implementation of Reconfigurable Antennas for different wireless applications | Mr. Ramesh Deshpande |
| Batch 3 | 16215A0434, 16215A0436, 16215A0435, 15211A04D5 | K Raju, P Samyuktha, Ch.Amulya, A.Haripriya | Design of dual band wearable antenna for body area network(Funded Project) | Dr. B R Sanjeev Reddy |
| Batch 4 | 15211A04D9, 15211A04F2, 15211A04F3, 16215A0426 | N Suguna, P Preetham, P Karuna, J Subhash | Design of OFDM system on Software defined radio platform (TI contest 1 st round cleared) | Dr. I A Pasha |
| Batch 5 | 15211A04G7, 15211A04E5, 16215A0448 | P Srikanth, N Ashok, M Manjunath | RF High frequency inductors | Dr.Nagesh Deevi |
| Batch 6 | 16215A0440, 16215A0439, 15211A04C7 | S Ravi kumar, K Aravind, Md.S. Hussain | Design of coupled inductor for wireless Applications | Mr. Ashok Kumar |
Activities in ACL
II Year II semester
| Date | 9.30AM-12.30PM | 1PM-4PM |
| 16-12-2017 | Basic Signal wave form characteristics | Basic learning on MATLAB 2014b |
| 23-12-2017 | Characteristics of signals | Signal examples on MATLAB 2014b |
| 30-01-2018 | Frame work on communication systems | Basic learning on SIMULINK |
| 06-01-2018 | IE3D Hands on training | Practice session |
| 20-01-2018 | IE3D examples and simulations | Task allocation |
| 27-01-2018 | Vector operations of Communication systems | Training on SIMULINK |
| 03-02-2018 | 2D/3D Coordinate system understanding | 2D/3D operators using MATLAB |
| 17-02-2018 | Mathematical operations of Electromagnetics | Design examples using MATLAB |
| 24-02-2018 | Explanation on UI/GUI interface tool boxes | Problem exercises using SIMULINK |
| 03-03-2018 | Power spectrum evaluation and understanding of CTS/DTS | Grant Test |
Activities in ACL
III Year II semester
| Date | 9.30AM-12.30PM | 1PM-4PM |
| 15-12-2017 | Training on HFSS Simulator | Hands on HFSS Simulator |
| 22-12-2017 | Novel Fractal antenna designs | Hands on HFSS Simulator |
| 29-01-2018 | Mini project presentation | Results verification |
| 05-01-2018 | Outcomes of the project | Project Documentation |
| 19-01-2018 | Evaluation of project contest | Proposal preparation |
| 27-01-2018 | Basics of Radar Signal processing | Hands on MATLAB 2014b |
| 02-02-2018 | Methods in tracking radar | Hands on MATLAB 2014b |
| 16-02-2018 | Matched filter designs of tracking radar | Hands on NI Tool box |
| 23-02-2018 | Seminar on Performance metrics of Synthetic Aperture Radar | Mini /Major Project Problem |
| 02-03-2018 | Interface design components of Radar systems | Grant Test |
Activities in ACL
IV Year II semester
| Date | 9.30AM-12.30PM | 1PM-4PM |
| 15-12-2017 | Exercise on task outcomes | Exercise on task outcomes |
| 22-12-2017 | Mini project Documentation | Simulations model verification |
| 29-01-2018 | Literature work on Project | Literature work on Project |
| 05-01-2018 | Fabrication of antennas | Calibration process of VNA |
| 19-01-2018 | Seminar on Effective paper writing skills | Research paper review |
| 27-01-2018 | Presentation of Mini projects | Prototypes to be prepared for testing |
| 02-02-2018 | Seminar on Multi band antennas | Techniques in hardware performance |
| 16-02-2018 | Testing of the prototypes to be carried | Verification and comparison of simulated and measured results |
| 23-02-2018 | Paper writing to be completed | Practice on TEST BED |
| 02-03-2018 | Presentations by the groups | Evaluation |
